Our ViewPlate microplates are engineered for bottom reading systems.
Leveraging years of assay and instrument experience in plate detection, Revvity designs better microplates for better performance that guarantees better results for all Revvity applications.
Packaging notes:
- 6007470 is packaged as 2 sleeves of 25 plates each. Lids are not included.
Well plate dimensions
Well format: 384-well
|
Description
|
Specification
|
|
Number of rows
|
16
|
|
Number of columns
|
24
|
|
Well volume
|
135 µL
|
|
Recommended working volume
|
25 µL- 125 µL
|
|
Height (mm)
|
14.4
|
|
Length (mm)
|
127.76
|
|
Width (mm)
|
85.48
|
|
Well diameter (mm)
|
3.3
|
|
Well depth (mm)
|
11.5
|
|
A1 to top offset (mm)
|
8.99
|
|
A1 to side offset (mm)
|
12.13
|
|
Well-to-well spacing (mm)
|
4.5
|
