Lab Consumables > Small Equipment and Accessories > Hotplates and Stirrers > Stirrers

RET control-visc

Supplied by IKA Works Inc

  • 0005020001 | RET control visc
  • 0005020001 | RET control visc
Average lead time: Call for Lead Time
ADD TO CART
Need Assistance?
Jump to Section
Product Description
Specifications
Additional Information
Media
Product Description
PATENTED WORLD FIRST: Safety magnetic stirrer with heating and integrated balance. Clear, multilingual TFT display makes it easy to set all parameters. Integrated temperature control feature enables connection of a temperature probe, placed directly in the medium, to control medium temperature with a high degree of precision. PT 100 temperature sensor is included. The stainless steel composite hot plate, reaching a temperature of 340 °C, enables rapid heating. RS 232 and USB interfaces enable pc control of the magnetic stirrer and documentation of all test parameters. "Lock" function prevents inadvertent changes of speed and temperature settings. As a safety feature, the current temperature is displayed when the unit is switched off but surface is still hot. Below 50 °C the display turns off automatically. - BNC socket for connection of a pH electrode - Adjustable temperature control mode: rapid heating and very accurate temperature control - Dual sensor for simultaneous control of heat transfer fluid temperature and medium temperature - Timer and countdown functions - Display of viscosity change trend - Detached magnet detection - Intermittent operation - Several modes of operation available - Safety circuit adjustable from 50 to 380° - Transparent protective cover included - Error code display for easy troubleshooting - Exact temperature and speed adjustment by means of digital display; even when function switched off - Suitable for unsupervised operation - Sealed casing (IP 42) ensures a long service life - Automatic switch-off of the heating function if the connected external temperature sensor is not immersed in the medium. Function selectable, timeout time adjustable (Error 5).
Specifications
Inventory Number:
IKA0005020001EA
Part Number:
0005020001
Supplier:
IKA Works Inc
Supplier's Lead Time:
Call for Lead Time
Quantity:
1 per EA
Contract Availability:
Country of Origin:
PRODUCT ACCESSORY:
Documents for qualification LAB (10006577) Factory Calibration Certificate LAB (10006579) IQ/OQ Documentation LAB (10006581) General Certificates (2.2 / 3.1) LAB (10010524) Qualification Execution (IQ/OQ) LAB (10010802) PT 100.70 Temperature sensor (20000440) PT 1000.50 Temperature sensor (3367600) PT 100.51 Temperature sensor (2600300) PT 1000.51 Temperature sensor (3377700) PT 100.53 Temperature sensor, coated (4499700) LR 1000.64 pH Electrode (4663300) H 16 V Support rod (1545100) H 16.3 Extension (25000622) H 44 Boss head clamp (2437700) H 38 Holding rod (3547700) H 104 Cover for RET control (4209500) H 29 Oil bath attachment, 1L (2829400) H 30 Oil bath attachment, 1.5L (2829500) H 1000 (4444401) H 1500 (4444501) H 3000 (4444503) H 5000 (4444505) H 8000 (4444508) IKAFLON 110 round (0793300) IKAFLON 10 round (5 pcs.) (4488600) IKAFLON 15 round (5 pcs.) (4488700) IKAFLON 20 round (5 pcs.) (4488800) IKAFLON 25 round (5 pcs.) (4488900) IKAFLON 30 round (5 pcs.) (4489000) IKAFLON 40 round (5 pcs.) (4489100) IKAFLON 50 round (5 pcs.) (4489200) IKAFLON 80 round (5 pcs.) (4489300) IKAFLON 25 glass round (5 pcs.) (4492200) IKAFLON® glass 30 Set (5 Pcs) round Magnetic stirring bars (4492400) IKAFLON 40 glass round (5 pcs.) (4492600) IKAFLON 50 glass round (5 pcs.) (4492800) IKAFLON 20 power (5 pcs.) (4493000) IKAFLON 30 power (5 pcs.) (4493200) IKAFLON 50 power (5 pcs.) (4493400) IKAFLON 25 slide round (5 pcs.) (4493800) IKAFLON 30 slide round (5 pcs.) (4494000) IKAFLON 40 slide round (5 pcs.) (4494200) IKAFLON 50 slide round (5 pcs.) (4494400) IKAFLON 20 ellipse (5 pcs.) (4494600) IKAFLON 25 ellipse (5 pcs.) (4494800) IKAFLON 30 ellipse (5 pcs.) (4495000) IKAFLON 35 ellipse (5 pcs.) (4495200) IKAFLON 40 ellipse (5 pcs.) (4495400) IKAFLON 50 ellipse (5 pcs.) (4495600) IKAFLON® 60 Set (5 Pcs) ellipse PTFE-coated Magnetic stirring bars (4495800) IKAFLON 70 ellipse (5 pcs.) (4496000) IKAFLON 10 cross (5 pcs.) (4496200) IKAFLON 20 cross (5 pcs.) (4496400) IKAFLON 25 cross (5 pcs.) (4496600) IKAFLON 30 cross (5 pcs.) (4496800) IKAFLON 38 cross (5 pcs.) (4497000) IKAFLON 37 bone (5 pcs.) (4497200) IKAFLON 54 bone (5 pcs.) (4497400) TRIKA 25 (5 pcs.) (4499300) TRIKA 35 (5 pcs.) (4499400) TRIKA 55 (5 pcs.) (4499500) TRIKA 80 (5 pcs.) (4499600) IKAFLON® 67 (1 Pc) beaker PTFE-coated Magnetic stirring bars (4497600) IKAFLON 74 beaker (4497800) IKAFLON® 103 (1 Pc) beaker PTFE-coated Magnetic stirring bars (4498000) IKAFLON® 125 (1 Pc) beaker PTFE-coated Magnetic stirring bars (4498200) IKAFLON 9 crown (5 pcs.) (4498400) RS 1 Set of magnetic stirring bars (1358600) RS 2 Set of magnetic stirring bars (4499100) RSE Stirring bar remover (1293100) H 11 Mains cable Euro plug (1091500) H 135.10 Square carrier without handle (25000832) H 135.11 Square carrier with handle (4448200) H 135.101 Block 16 x 4 ml (25000626) H 135.102 Block 16 x 8 ml (25000627) H 135.103 Block 9 x 16 ml (25000628) H 135.104 Block 4 x 20 ml (25000629) H 135.105 Block 4 x 30 ml (25000630) H 135.106 Block 4 x 40 ml (25000631) H 135.107 Block 100 ml (25000632) H 135.108 Block 250 ml (25000633) H 135.20 Flask carrier 100 ml without handle (25000634) H 135.21 Flask carrier 100 ml with handle (4448300) H 135.201 Flask inlay 10 ml (25000636) H 135.202 Flask inlay 25 ml (25000637) H 135.203 Flask inlay 50 ml (25000638) H 135.25 Flask carrier 250 ml without handle (25003280) H 135.26 Flask carrier 250 ml with handle (20007954) H 135.30 Flask carrier 500 ml without handle (25000639) H 135.31 Flask carrier 500 ml with handle (4448400) H 135.301 Flask inlay 100 ml (25000641) H 135.302 Flask inlay 250 ml (25000642) H 135.40 Flask carrier 1000 ml without handle (25000833) H 135.41 Flask carrier 1000 ml with handle (4448500) H 135.401 Flask inlay 500 ml (25000644) H 135.50 Flask carrier 2000 ml without handle (25000834) H 135.51 Flask carrier 2000 ml with handle (4448600) H 135.501 Flask inlay 1000 ml (25000645) WiCo RET control-visc (20007259) LABLIFT m (4022400) Labworldsoft® 6 Pro (20017366) Labworldsoft® 6 Starter (20019397) labworldsoft® (4720000) Labworldsoft® 6 Lite (20017364) PC 1.1 Cable (2616700) BC 1000 Beaker cap (20003417) HG 600 Heating jacket (20003416) HG 1000 Heating jacket (20003415) PT 1000.53 Temperature sensor, dual, coated (4499800) R 350 Universal clamp (1752900) PC 1.3 Cable (25005322)
TECHNICAL DATA:
Number of stirring positions: 1 Stirring quantity max. per stirring position (H2O) [l]: 20 Maximum load [kg]: 25 Motor rating output [W]: 9 Direction of rotation: right Speed display set-value: TFT Speed display actual-value: TFT Speed adjustment: Turning knob Speed range [rpm]: 50 - 1700 Setting accuracy speed [rpm]: 10 Stirring bar length [mm]: 20 - 80 Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h) [K]: +17 Heat output [W]: 600 Temperature display set-value: TFT Temperature display actual-value: TFT Temperature unit: °C / °F Heating temperature range [°C]: Room temp. + device self heating - 340 Heat control: Turning knob Temperature setting range [°C]: 0 - 340 Temperature setting resolution of heating plate [K]: 0.1 Connection for ext. temperature sensor: PT100/PT1000 (dual sensor) Characteristics in the medium with temperature sensor: 1l M50 Oil at H1500 Temperature medium max. [°C]: 270 Temperature setting resolution of medium [K]: 0.1 Adjustable safety circuit [°C]: 50 - 380 Set-up plate material: stainless steel 1.4301 Set-up plate dimensions [mm]: Ø 135 Automatic reverse rotation: no Intermittent mode: yes Viscosity trend measurement: yes Break detection stirring bar: yes Timer: yes pH measurement: yes / BNC socket female Graph function: yes Programs: yes Sensor in medium detection: yes Weighing function: yes Weighing range [g]: 10-5000 Weighing accuracy: ±(0.3%+2) g Load capacity weighing function max. [kg]: 5 Heating rate (1l H2O in H1500) [K/min]: 7 Dimensions (W x H x D) [mm]: 160 x 85 x 270 Weight [kg]: 2.7 Permissible ambient temperature [°C]: 5 - 40 Permissible relative humidity [%]: 80 Protection class according to DIN EN 60529: IP 42 RS 232 interface: yes USB interface: Micro-USB Analog output: no Voltage [V]: 220 - 240 Frequency [Hz]: 50/60 Power input [W]: 650
Warranty:
2+1
