Product Description

    \n
  • 20-3000 rpm
  • \n
  • 341 Ncm (480 in-oz)
  • \n
  • 60 L (15.5 US Gallons)
  • \n
\n  \n \nGeneral purpose stirrer with versatility for buffers, media, gels, lotions and slurries. Digital display of speed and torque, adjustable chuck up to 10 mm (? in), quiet and maintenance free. \n
The perfect combination of higher torque and higher speed, Caframo’s Universal 3030 offers versatility to conquer the widest range of applications by a bench top stirrer.  From larger batches of buffers and media to lotions and slurries, this stirrer will exceed your expectations.  Ideal for workplaces with changing mixing needs as the business evolves, the 3030 will provide the most value for your overhead stirrer investment. \n \n“I have purchased several of these over the years.  They work great, never seem to break.  I do not have any improvements to suggest."  Energy technologies innovator. \n \nCaframo stirrers are quiet, dependable, maintenance free and ideal for continuous use. Included in each purchase: Overhead stirrer motor, chuck, chuck guard, chuck key, support rod, power cord, manual in four languages (English, French, Spanish and German), calibration certificate and three year warranty. \n \nRequest a Quote \n
Specifications
Inventory Number:
EIJBDC3030EA
Part Number:
BDC3030
Supplier:
CAFRAMO LIMITED
Supplier's Lead Time:
Call for Lead Time
Quantity:
1 per EA
Contract Availability:
Country of Origin:
Canada
Ambient Temperature Operation:
5-40 °C (41-104 °F)
Chuck Guard:
Yes
Chuck Maximum Shaft Diameter:
10 mm (? in)
CSA listed to Canada and US standards:
Approvals
Frequency:
50/60 Hz
Housing:
Cast aluminum
IP Rating:
IP42
Output Power:
150 Watts (? hp)
Relative Humidity Operation:
80%
Rotation Direction:
Clockwise only
Speed:
20-3000 rpm
Speed - High Range:
600-3000 rpm
Speed - Low Range:
20-600 rpm
Speed Accuracy:
± 1 rpm or ± 1% of reading
Speed Display:
Yes
Through Shaft:
Yes
Timer:
No
Torque Accuracy:
± 12 Ncm (± 1 in-lb) or ± 5% of reading
Torque Display:
Yes
Torque Maximum:
341 Ncm (30 in-lbs = 480 in-oz)
Torque Maximum - High Speed:
68 Ncm (6 in-lbs = 96 in-oz)
Torque Maximum - Low Speed:
341 Ncm (30 in-lbs = 480 in-oz)
Viscosity Maximum:
50\,000 mPas (50\,000 cP)
Voltage:
120 volt/220 volt
Volume Maximum:
60 L (15.5 US Gallons)
Weight:
5 kg (11 lb)
Zero Torque:
Yes
