Reversing Digital

Supplied by CAFRAMO LIMITED


  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
  • BDC2010 | Reversing Digital Overhead Stirrer 100 240 volt No
Average lead time: Call for Lead Time
Need Assistance?

Jump to Section
Product Description

    \n
  • 40-2010 rpm
  • \n
  • 90 Ncm (127 in-oz)
  • \n
  • 25 L (6.5 US Gallons)
  • \n
\n  \n \nUltimate versatility with programmable clockwise and counterclockwise stirring. Digital control optimizes polymerization, crystallization, and QC/QA testing. Countdown timer, cycle timer, adjustable chuck up to 10 mm (? in), quiet and maintenance free. Caframo has a history of great innovation in overhead stirrers. The BDC2010 stirrer is no exception and delivers 25% more power than the BDC2002 while keeping the same compact footprint, Stirlight™ and through shaft. The BDC2010 works smarter and allows the user complete mixing control. The stirring direction can be changed with the touch of the reversing button. The countdown timer times a stirring activity and beeps when completed. Engage the Auto Start feature to start or resume stirring automatically when power is supplied by control equipment or after a power outage. In xRx mode the stirrer is set up to continuously reverse from one direction to the other for a set length of time. (Picture the agitation mode of a top loading washing machine!) \n \nRequest a Quote
Specifications
Inventory Number:
EIJBDC2010EA
Part Number:
BDC2010
Supplier:
CAFRAMO LIMITED
Supplier's Lead Time:
Call for Lead Time
Quantity:
1 per EA
Contract Availability:
Country of Origin:
Canada
Ambient Temperature Operation:
5-40 °C (41-104 °F)
Auto Start:
Yes
Chuck Guard:
Available
Chuck Maximum Shaft Diameter:
10 mm (? in)
CSA listed to Canada and US standards:
Approvals
Frequency:
50/60 Hz
Housing:
Epoxy-coated zinc
IP Rating:
IP42
Output Power:
50 Watts (1/15 hp)
Relative Humidity Operation:
80%
Rotation Direction:
Clockwise and counterclockwise
Speed:
40-2010 rpm (clockwise and/or counterclockwise)
Speed Accuracy:
± 1 rpm or ± 3% of reading
Speed Display:
Yes
Through Shaft:
Yes
Timer:
Countdown 1-2000 minutes (33.3 hours)
Torque Display:
No
Torque Maximum:
90 Ncm (7.9 in-lbs = 127 in-oz)
Viscosity Maximum:
20\,000 mPas (20\,000 cP)
Voltage:
100-240 volt must use Caframo power supply
Volume Maximum:
25 L (6.5 US Gallons)
Weight:
Power Supply: 0.6 kg (1.2 lb), Stirrer: 3.0 kg (7 lb)
xRx Mode:
1-2000 minutes (33.3 hours)
Zero Torque:
No
Additional Information
