Tube Screw Cap, External Thread, 96-format, bulk; white; 960 caps.
Tube Screw Caps developed to exceed the demands of sample security, management and tracking in modern high-density storage applications
- Optimal seal quality and sample security
- Suitable for cryogenic storage
- Made from high-quality virgin PP
- Available in cap carriers or bulk
- For use with external/internal thread tubes
Developed to exceed the demands of sample security, management and tracking in modern high-density storage applications. Designed for reduced sample loss: significant amounts of liquid can become trapped within a standard design screw cap, resulting in potential loss of valuable sample.
Studies demonstrate that Azenta Life Sciences cap design, with a reduced hollow, reduces this effect by lowering liquid retention whilst maintaining seal quality. This hollow area on the cap can catch sample, and surface tension then makes cap removal difficult.
Compatible with all Azenta Life Sciences sample storage tubes with a screw top, caps are available for use with either external or internal thread Azenta Life Sciences screw top tubes. Manufactured from high-quality virgin polypropylene.
Key Features:
Practical Design:
- High chemical resistance
- Autoclavable
- Available in up to 10 different colors to aid sample identification
- Suitable for sealing external and internal thread tubes
- Broad operating temperature range*: -196°C to +121°C
*Not for use in liquid phase nitrogen
Options:
External thread screw caps, standard
- A deforming compression seal more effective than a silicone alternative
- A non-silicone seal means the cap can never be over-tightened
- Caps and tubes are manufactured from the same material, preventing differential expansion during freeze-thaw cycles
- A double-start thread engages in a maximum rotation of 180°, thereby facilitating automation
External thread screw caps, automation friendly
- Automation friendly options, available in Azenta Life Sciences cap carriers for use with automated capping/de-capping systems
- Automation friendly screw caps provide flexibility to use tubes across a range of industry-recognized automated tube handling platforms
- Internal thread screw caps, automation friendly
- Automation friendly co-molded screw caps for internal thread tubes eliminate the possibility of over tightening
- Co-molded caps eliminate the failures in caps using a silicone O-ring
- Double start thread engages in a maximum rotation of 180°, facilitating automation
.
| Parameter |
FrameStar 384 Well Skirted PCR Plate |
| Plate length |
127.76 ± 0.25mm |
| Plate width |
85.48 ± 0.25mm |
| Plate height |
10.60 ± 0.25mm |
| Well depth |
9.60 ± 0.10mm |
| Well diameter |
3.10 ± 0.10mm |
| Total well capacity |
55µl |
| Working volume |
<30µl |
| Distance to center of A1 from top edge |
8.99 ± 0.25mm |
| Distance to center of A1 from left edge |
12.13 ± 0.25mm |
| Pitch (distance between A1 and A2) |
4.50mm |
